COLTRI

COLTRI Mini Compact 100 EM 2.2 kW 240V single phase

€3,245.00
Tax included Upon order - please ask us before ordering
Price excluding tax / DOM-TOM €2,704.17
CSC000120C

COLTRI Mini Compact 100 EM 2.2 kW 240V single phase

  • Flow rate : 100L/min or 6m3/h
  • 230-240 volt electric motor
  • Compact, solid, streamlined chassis with included filling hose.
  • Automatic stop and flow in option.
Upon order - please ask us before ordering
Shipping
Free Shipping From 89 € for France * * See conditions
Product return & exchange 14 days to change your mind
24/7 support 24/7 customer return guaranteed
100% secure payment By credit card, bank transfer, PayPal or check
COLTRI Mini Compact 100 EM 2.2 kW 240V single phase

COLTRI Mini Compact 100 EM 2.2 kW 240V single phase

The Coltri Mini Compact Compressor is a special version of the MCH6 compressor that has been designed to meet high pressure air requirements, including breathing air, small industrial and laboratory processes, shooting sports, and small paintball structures. This version is equipped with a 230-240 volt single phase electric motor for users who do not have a three phase power supply.

The welded frame of the COMPACT range is compact, solid and equipped with a flexible output,

The welded frame of the COMPACT range is compact, solid and equipped with a flexible inflation outlet, a robust compression block, and carrying handles. It is suitable for transport and can be equipped with optional purges and automatic shut-off. The MCH6-V17 compression block is designed for long life and low cost, with ground cylinders and ion nitriding for high surface hardness.

The frame is fully enclosed to protect the machine from falling objects and to protect the operator, and the epoxy powder coating provides effective protection in hostile environments. The compressor is equipped with multiple filtration systems to ensure air quality in accordance with EN 12021:2014, with final filtration for oil, odour and water. It is equipped with various options, such as manual or automatic blowdown, safety valve or automatic shutdown, hour meter, pressure holding valve for industrial processes on fixed networks, and a dual pressure system.

Technical data sheet

  • Height 42.7 cm
  • Width 59,2 cm
  • Depth 38 cm
  • Weight 47 Kg
  • Operating Pressure 230, 300 or 330 bars
  • Electrical Energy single phase
  • Motor Power 2.2 KW / 230 Volts / 50 Hz
  • Sound Intensity In DB(A) At 1m 72
  • Soundproofed compressor NO
  • Automatic purge OPTIONAL
  • Automatic shutdown OPTIONAL
  • Refillable Filtration NO
  • Number Of Flexible Outlets With Valve 1
  • Compressor Mobility Mobile Compressor

Technical Data

  • COMPRESSOR UNIT ICON 100
  • Reference SC000120C (230V-50Hz) SC000121C (230V-60Hz) SC000120 I (230V-50HZ) stainless steel
  • FLOW 100 l/min
  • MOTOR SINGLE-PHASE ELECTRIC
  • WORKING PRESSURE 232 - 330 bar / 3365 - 4786 psig
  • POWER 2.2 Kw (230 V - 50/60 Hz)
  • DIMENSIONS (W x H x D) 59,2 x 42,7 x 38 cm
  • NET WEIGHT APPROX. 47 Kg
  • POWER LEVEL / ACOUSTIC LpA 72 dB
