Caisson étanche MX-NINJA V MARELUX

Marelux MX-NINJA V Waterproof Housing

This anodised aluminium housing is designed to accommodate the Atomos Ninja V, Ninja V+ and Ninja Ultra monitor-recorders. It provides full protection for your 5-inch screen during underwater shoots at depths of up to 100 metres. Its compact design keeps the footprint small whilst providing positive buoyancy underwater, making your entire video setup lighter. Thanks to the fully integrated remote controls, you can adjust your exposure and focus settings without taking your eyes off your subject.

Technical specifications for Marelux MX-NINJA V Waterproof Housing

• Housing made from aerospace-grade aluminium with an anodised finish.
  • Hydrostatic pressure resistance tested to 100 metres.
  • Compatible with 5-inch Atomos Ninja V, Ninja V+ and Ninja Ultra monitors.
  • Full mechanical interface that translates touch controls into waterproof physical buttons.
  • Highly visible fluorescent green double seal for debris inspection.
  • M16-sized electronic vacuum valve included with a pull-type safety mechanism.
  • Expanded connectivity supporting HDMI 2.1 bulkhead connectors and SDI cables.
  • Out-of-water weight of 1.6 kg providing slightly positive buoyancy when submerged.
  • Top and bottom mounts for standard 1-inch ball heads.

Accessoires fournis in Marelux MX-NINJA V Waterproof Housing

• M16 electronic vacuum valve pre-installed.
  • Manual air extraction pump for activating the vacuum system.
  • Spare main O-ring in fluorescent green.
  • Silicone grease for lubricating seals.

Diveavenue's expert opinion for Marelux MX-NINJA V Waterproof Housing

The MX-NINJA V is the housing we tested for you in demanding video setups. What I like about it is how compact it is compared to industry standards, which makes it much easier to transport when travelling. Underwater, its slightly positive buoyancy offsets the weight of the articulated arm and the battery, making handling the camera much less tiring overall. The transition from the Atomos’ touch controls to the housing’s physical buttons is seamless, allowing you to switch to focus peaking or false colour instantly whilst shooting.

Frequently Asked Questions (FAQ)

Can the touchscreen be used once it is inside the housing ? The touchscreen cannot be operated directly with your fingers, but the housing features precise mechanical levers and push-buttons that allow you to access all the device’s menus and functions whilst underwater.

Is the housing compatible with other brands of camera bodies ? Exactly: simply fit your main camera housing with a suitable M24 or M16 bulkhead to route the Marelux HDMI or SDI connection cable through it.

What is the purpose of the included vacuum system ? This device allows you to evacuate the air from inside the housing before diving. An LED provides visual confirmation that the system is completely watertight, thereby eliminating the stress of water ingress whilst filming.
