COLTRI Force Four HD 400 EM, 450 EM, 650 EM high-pressure compressor

Stationary high-pressure compressor.
3 flow rates to choose from: COLTRI Force Four HD 400 EM (400 L/min), HD 450 EM (450 L/min), HD 650 EM (650 L/min)
Purified breathing air, compliant with DIN EN 12021.
Designed for intensive applications and hot environments.
Equipped with 4 inflation connections and automatic condensate drainage.

Quotation on request

Compressor flow

In stock

Shipping

Free Shipping From 89 € for France * * See conditions

Product return & exchange 14 days to change your mind

24/7 support 24/7 customer return guaranteed

100% secure payment By credit card, bank transfer, PayPal or check

COLTRI Force Four HD High-Pressure Compressor 400 EM, 450 EM, 650 EM

COLTRI Force Four HD 400 EM, 450 EM, 650 EM high-pressure compressor

The COLTRI FORCE FOUR HD compressor is a high-pressure solution designed to deliver superior quality breathing air (EN 12021 standard), even in hot or poorly ventilated environments. With its 4-stage pumping unit and automatic purge, it ensures consistent performance for filling large capacities.

Comparison table of the different versions in the Force Four HD range

Feature	400 EM	450 ET	650 ET
Charge Rate (Flow)	400 l/min	450 l/min	650 l/min
Motor Type	Single-phase electric	Three-phase electric	Three-phase electric
Power	7.5 kW	7.5 kW	11 kW
Operating Voltage	230 V - 50 Hz	400 V - 50 Hz	400 V - 50 Hz
Max Service Pressure	300 BAR	420 BAR	420 BAR
Weight	250 kg	250 kg	260 kg
Outlets	4 cylinder connections	4 cylinder connections	4 cylinder connections
Dimensions (H x W x D)	79.6 x 115 x 60 cm	79.6 x 115 x 60 cm	79.6 x 115 x 60 cm
Filtration	Hyperfilter	Hyperfilter	Hyperfilter

Technical specifications

Mobility: stationary.
Maximum operating pressure: 300 BAR (depending on model 400 EM).
Supported gases: breathable air EN 12021, Nitrox (max. 40% O2), helium, nitrogen.
Pump unit: 4 stages in aluminium and forged steel.
Lubrication: forced.
Cooling: inter-stage optimised for hot environments.
Electric motor (400 EM model): single-phase, 7.5 kW.
Filtration: Hyperfilter system with moisture separators (compliant with DIN EN 12021).
Electrical panel: pressure switch, purge timer and inter-stage pressure gauges.
Maintenance: automatic condensate drain.
Options: Megafilter cartridges and Presec system (filter saturation control) available as options.
Ideal use: intensive professional applications, industrial environments and tropical countries.

Accessories included

4 cylinder connections (DIN 232, DIN 300 or INT/YOKE 232 bar).
4 x 1.2 m hoses.
Pressure maintenance valve.
Hyperfilter filtration system.
Integrated controls and alarms (oil level, pressure switch).
Oil pump and inter-stage pressure gauges.

The Diveavenue expert choice :

The Force Four compressor range is designed for heavy-duty use. Every aspect ensures exceptional longevity, featuring a reinforced four-stage compressor block complete with full automation and operational controls.

This high-pressure compressor is ideal for applications requiring intensive use, such as dive clubs in tropical regions or industrial operations.

For use in tropical climates, we also recommend adding the Coltri Tornado air dryer.
